- Portable power systems
- Other industrial applications
- Super-excellent flexibility
- Water resistant and flame retardant
- Excellent impact and abrasion resistant
- Ozone, sunlight, oil, grease, weather, chemical resistant
CONSTRUCTION:
- Conductors: Extra flexible strand bare copper (Standard Flex tin copper), B-172 and ICEA S-75-381/NEMA WC70
- Separator: Tape separator between conductor and insulation
- Insulation: Ethylene-propylene rubber (EPR), ICEA S-95-658 sec.3.21, table 3-6
Reinforcement: Nylon open braid applied over insulation
Jacket: Black heavy duty CPE thermoset compound, ICEA S-75-381/NEMA WC70 sec 3.21, table 3-4
TECHNICAL DATA:
Conductor Material |
Extra flexible strand bare copper (Standard Flex tin copper), B-172 and ICEA S-75-381/NEMA WC70
|
Conductor class | * |
Core insulation | EPR |
Core identification | * |
Stranding | * |
Outer sheath |
Black heavy duty, thermoset CPE, ICEA S-95-658 NEMA WC70, AAR RP-586
|
Sheath colour | Black |
Rated voltage [V] | 2000V |
Testing voltage [V] | * |
Conductor resistance | * |
Insulation resistance | * |
Current carrying capacity | * |
Min. bending radius fixed [xd] | * |
Min. bending radius moved [xd] | * |
Working temp fixed min/max [C] | -40°C up to +90 |
Working temp moved min/mac [C] | -40°C bis +90 |
Temp at conductor max | +90°C |
Burning behaviour | * |
Approvals |
UL: E207132 – Oil Resistant; Oil Resistant Inners; Sunlight Resistant; 90°C Wet or Dry C(UL): E207132 – FT1; FT5; -40°C +90°C MSHA: P-7K-268101
|
PART NUMBER | CORES | OUTER DIAMETER | COPPER WEIGHT KG/100M |
WEIGHT KG/100M |
---|---|---|---|---|
1 x AWG 8 | 11.2 | 21.6 | ||
1 x AWG 6 | 12.9 | 29.8 | ||
1 x AWG 4 | 14.3 | 37.9 | ||
1 x AWG 2 | 16.5 | 55.8 | ||
1 x AWG 1 | 18.5 | 70.7 | ||
1 x AWG 1 / 0 | 19 | 78.9 | ||
1 x AWG 2 / 0 | 20.3 | 96.7 | ||
1 x AWG 3 / 0 | 21.7 | 111.6 | ||
1 x AWG 4 / 0 | 24.9 | 144.4 | ||
1 x 250 MCM | 25.4 | 168.2 | ||
1 x 350 MCM | 28.8 | 211.6 | ||
1 x 500 MCM | 31.9 | 284.7 |
